Micronics Portaflow Portable Clamp-On Ultrasonic Flow Meter Kits
Quick Answer
The Micronics Portaflow clamp-on ultrasonic flow meter kit measures liquid flow from outside the pipe. You do not need to cut pipes or stop production. Silver Automation Instruments stocks these portable kits and delivers them to water plants, sugar mills, and chemical sites across Southeast Asia, Oceania, Africa, and the Middle East.
What Makes the Portaflow Kit Different
Most flow instruments force you to shut down the line, weld flanges, and wait for a fitter. The Portaflow kit avoids all that. You attach two clamp-on sensors to the outside of a pipe, apply coupling gel, enter the pipe parameters, and get a flow reading in minutes. The technology uses transit-time ultrasonic signals. Sound pulses travel with the flow and against the flow. The meter calculates the time difference and gives you velocity and volumetric flow right on the LCD.
This works best on clean liquids that do not carry large amounts of bubbles or solids. Water, treated wastewater, glycol, light oils, and many chemicals work well. Pipe materials can be carbon steel, stainless steel, ductile iron, copper, or PVC. The kit handles pipe diameters from DN15 all the way up to DN2500, so you can meter a small heat exchanger loop or a large cooling tower main header with the same unit.
The kit comes in a hard transport case. Inside you find the transmitter, two clamp-on transducers, transducer mounting hardware, a tube of acoustic coupling compound, a power supply, and a USB cable for data export. Total weight is around 4.5 kg. The built-in battery lasts more than 8 hours at field sites with no mains power. Engineers in Australia and Nigeria have used this same configuration to verify pump flows on remote bore fields.
Accuracy under fully developed flow profile conditions is typically plus or minus 1 percent of reading. The transmitter logs over 200 000 data points with time stamps. You can transfer the logger file to a PC and review trends later. This is a real measurement tool, not a rough indicator.
Where We See the Portaflow Used Every Day
Water and wastewater plants are the most common call we get. Operators clamp the sensors onto existing ductile iron mains and verify the fixed mag meters. A utility in Manila did exactly this last monsoon season. They compared the Portaflow reading against an in-line electromagnetic flow meter on a DN600 raw water line and got deviation below 1.5 percent. No shutdown, no bypass. Just quick field validation.
HVAC service companies use the portable kit for chiller flow audits. A facility manager in Jeddah checked chilled water flows across three buildings over a weekend. The clamp-on approach saved them from breaking the insulation on chilled water risers. Sugar mills in Thailand and Kenya trust the Portaflow to balance process water and thin juice lines. Because the transducer rails adjust easily, the same kit measured a DN25 condensate pipe in the morning and a DN200 juice pipe after lunch.
Chemical plants in Latin America apply the kit for temporary flow surveys on metering skids. They often deal with solvents and mild acids. The ultrasonic signal passes through PTFE-lined pipes without any wetted sensor corrosion risk. Oil and gas depots use the Portaflow to track fire water pump performance during annual tests. The logger captures the entire pump curve, and they email the CSV file to consultants for compliance.
One small marine repair yard in Panama keeps a Portaflow kit for engine cooling water checks on vessels. Because they never touch the seawater, the ultrasonic method eliminates any corrosion concern. They have used the same kit for five years with zero repairs.
Technical Specifications You Need Before You Quote
Flow velocity range is 0.01 m/s to 12 m/s. Pipe wall thickness support covers common schedules up to 25 mm of carbon steel. The transmitter display shows flow rate in multiple units: m3/h, L/min, US GPM, kg/h. You can also monitor totalized volume, si
Pipe diameter input resolution goes down to 0.1 mm. The wall thickness value needs to be accurate. We always tell customers to measure it with an ultrasonic thickness gauge. Do not trust the nominal schedule. A pipe that the plant says is 6.4 mm thick often measures 6.1 mm after 10 years of service. That small difference shifts the flow reading noticeably.
The meter supports liquid temperatures from minus 40 degrees Celsius to 150 degrees Celsius with the standard transducers, but keep ambient temperature around the transmitter below 50 degrees Celsius. IP rating is IP67, meaning you can use it in rain at a construction site. The menu is touch-key driven with a backlit graphic display. Most engineers we train need about 10 minutes to feel confident.
How Silver Automation Instruments Supports Your Portaflow Order
We are not a drop-ship website. We hold demo units in our office, and we test clamp-on kits on actual pipes before dispatch. Our engineers check transducer cables, battery health, and data logger function. This small step catches problems before the case reaches your customs agent.
We ship the Micronics Portaflow kit from stock to Australia, Vietnam, UAE, Brazil, and Nigeria within 3 business days. Every kit includes a calibration certificate traceable to national standards. For customers who need a formal third-party calibration, we can arrange that at an ISO 17025 lab in Singapore or Germany before shipping. This paperwork matters for ISO 9001 audits.
After the sale, our technical team answers WhatsApp messages within 1 hour during Asia business hours. We have walked a plant manager in Durban through a signal setup on a gritty pipe surface using photos and simple step-by-step instructions. You do not need to wait for a field service engineer to fly in.
Common Questions from Engineers and Buyers
Does the Portaflow work on old pipes with scale? Thick hard scale blocks the ultrasonic signal. Light rust or internal coating usually works if you clean the outside surface to bare metal. We ask you to check signal strength on the display. A signal above 60 percent is reliable.
Can I measure diesel or heavy fuel oil? The Portaflow is designed for single-phase liquids without large entrained air. Clean diesel works. Heavy fuel oil at low temperature is too viscous and attenuates the signal. Light oils below 300 cSt viscosity give good results.
What pipe materials work? Carbon steel, stainless steel, cast iron, ductile iron, copper, brass, and rigid PVC. Concrete and GRP pipes with a rough inner surface are difficult. We always recommend a trial before you buy if your pipe is lined or buried.
Do I always need coupling gel? Yes. The kit includes a tube of acoustic couplant. For permanent installations, we sell silicone rubber coupling pads. The gel is essential for every single measurement.
How fast can you deliver to Ghana? We dispatch within 3 working days. Shipping to Accra takes 5 to 7 working days by air freight. We use DHL or FedEx and share the tracking number immediately.
Get a Specific Portaflow Quotation Now
Tell us your pipe outer diameter, wall thickness, pipe material, liquid type, and operating temperature. Include your country and the required flow range. Our sales engineers reply within the same working day. Write to [email protected], call +86-135-1213-1526, or send a WhatsApp message to 86-135-12131526. You can also reach us on WeChat at +86 13512131526. Silver Automation Instruments delivers better flow measurement, one clamp-on kit at a time.
