Coriolis Flow Meter GIF: Graphical Overviews of Vibrating Fluid Dynamics
Quick Answer: A Coriolis flow meter GIF shows the vibrating tube and the phase shift caused by mass flow. The visual helps process engineers and procurement teams understand how the meter detects mass flow directly before they request a quote. Silver Instruments supplies Coriolis mass flow meters from DN15 to DN300 with 4-20 mA HART, Modbus, and ATEX options.
What the GIF Visualizes in a Coriolis Meter
A Coriolis flow meter GIF breaks down a short dynamic sequence. You see the tube drive vibration at rest. Then you see the inlet side and outlet side bend in opposite directions when fluid passes through. The movement amplitude is small. In a DN25 meter the tube movement may be less than 1 mm at 80 Hz to 120 Hz. The sensors pick up the time difference between the two ends.
That time difference is proportional to mass flow. Volume flow does not give you the same result. Temperature changes do not fool the mass flow reading. This is the main point engineers look for in a Coriolis flow meter GIF.
Where the GIF Helps in Real Plants
Most engineers skip the long theory. They want a fast view of how the vibrating tube reacts to flow, density, and gas bubbles. We have seen this on customer sites many times. A dairy plant in New Zealand used a Coriolis flow meter GIF to train operators on raw milk batching. The operators saw why a two-phase flow spike affected the drive signal. A paint manufacturer in Vietnam asked for a GIF before buying a DN15 Coriolis meter for solvent dosing. They wanted to check the vibration cycle against their batching speed.
In the Middle East, a desalination plant in Oman used a Coriolis flow meter GIF to explain brine concentrate measurement to a new shift team. The visual cut training time by about half. This is not a theory test. It is a field tool.
Silver Instruments Coriolis Meter Specs and Typical Use
Silver Instruments builds Coriolis mass flow meters for liquid and gas service. Sizes start at DN15 and go up to DN300. Wetted parts are available in 316L stainless steel, Hastelloy C, and tantalum. Process temperature range is -200 °C to 350 °C. The standard output is 4-20 mA HART with pulse, Modbus RTU, and RS485 options. Accuracy for liquids is 0.1 percent of rate. Density measurement is standard. A built-in PT100 sensor reports process temperature.
In practice, a DN50 meter on a chemical batching line handles flows from 0 to 12,000 kg/h. A DN80 meter on a fuel oil line in Chile runs at 35 °C and 4 bar with 0.15 percent accuracy. Th
When to Send Process Data for a Quote
Here is the thing. A Coriolis flow meter GIF helps you understand the measurement principle. But the correct size depends on your flow range, pressure, temperature, viscosity (cP), and gas content. Send us your pressure (bar), temperature (°C), pipe size (DN), and flow range (kg/h). If you are also comparing an electromagnetic flow meter on a water line, add conductivity in µS/cm. We return a model selection with price and lead time. You do not need to guess the size from a GIF.
For example, a customer in the Philippines asked for a DN25 meter for coconut oil at 85 °C and 1,200 kg/h. We recommended a 316L stainless steel body with PTFE lining and 4-20 mA HART output. The meter shipped within 12 days. That is the level of detail we need.
Coriolis Flow Meter GIF vs Field Data
A GIF gives you the dynamic picture. Field data gives you the sizing result. Use the GIF for training and for a quick understanding of the meter. Use the process data for purchase. Both belong in the decision. If you need a visual to send to your maintenance team, ask us for the Coriolis flow meter GIF pack. We can supply it with the quote.
Contact Silver Instruments
For a quote or a technical check, contact Silver Instruments. Tel: +86-135-1213-1526. Whatsapp: 86-135-12131526. WeChat: +86 13512131526. Ask for the Coriolis flow meter GIF and a sizing sheet. We reply within one business day.
FAQ
Q: What does the Coriolis flow meter GIF actually show?
A: It shows the vibrating tube at rest and under mass flow. The phase shift between the inlet and outlet legs is the visual proof of direct mass flow measurement.
Q: Can I use a Coriolis meter for gas flow?
A: Yes. Silver Instruments supplies Coriolis meters for gas service. You need to share pressure, temperature, and molecular weight or gas composition for correct sizing.
Q: What is the smallest pipe size you offer?
A: DN15. This size works for low flow dosing and pilot plants. We have quoted DN15 meters for paint solvents and food additives.
Q: How much does a Coriolis flow meter cost?
A: Price depends on size, wetted parts, approvals, and outputs. Send us your flow range (kg/h), pressure (bar), temperature (°C), and pipe size (DN). We will send a specific price.
Q: Do you offer ATEX approval?
A: Yes. We supply ATEX Zone 1 and Zone 2 options for hazardous areas. Tell us the zone classification and gas group when you request a quote.
