1. Portable Doppler Ultrasonic Flow Meter for Drainage Port Monitoring and Channel Monitoring

The AMT-LSX-2 Doppler Ultrasonic Flow Meter can efficiently complete the monitoring tasks of drainage ports and channels. The specific analysis is as follows: real-time monitoring of flow velocity and flow rate is applied for drainage port monitoring: the device has a flow velocity measurement range of 0.02~5m/s and a resolution of 1mm/s, which can accurately capture and sell instantaneous flow velocity changes at drainage ports. Through the velocity area method flow measurement technology, it supports flow calculation under full and non full pipe conditions, and users can freely set the cross-sectional water level relationship to adapt to different drainage outlet structures. Outstanding anti-interference ability: The design without mechanical rotating parts completely avoids problems such as sediment blockage and water grass entanglement, making it particularly suitable for environmental assessment of drainage outlets with high suspended sediment content or floating objects. The anti-corrosion shell can resist long-term corrosion from sewage, ensuring the stability of the equipment. Convenient data management: The supporting data receiving software supports real-time flow rate, flow data reading, and cumulative flow statistics, helping management personnel quickly evaluate changes in drainage volume and providing a basis for sewage treatment scheduling. Channel monitoring application with wide range and high-precision measurement: The equipment can cover the common flow velocity range of the channel, and a resolution of 1mm/s ensures measurement accuracy under low flow velocity conditions. The high response time fea

ture enables real-time data refresh, meeting the monitoring needs of frequent fluctuations in channel water levels. Multi parameter synchronous monitoring: In addition to flow rate and flow rate, the built-in high-precision temperature sensor can synchronously measure water temperature and improve measurement accuracy through sound speed compensation function. The design of the fluid dynamics shell reduces interference with the flow state of the water body and ensures the reliability of data under natural flow conditions in the channel. Long term stability guarantee: The linear measurement characteristics of factory calibration eliminate the need for frequent on-site calibration and reduce maintenance costs. The anti-corrosion shell and non mechanical component structure enable the equipment to operate stably for a long time in damp and muddy environments. Summary of core advantages: Environmental adaptability: anti-corrosion shell and fluid mechanics design ensure that the equipment can continue to work under harsh conditions such as sewage from drainage outlets and sediment in channels. Measurement accuracy: With wide range, high resolution, and sound velocity compensation technology, it achieves accurate measurement of multiple parameters such as flow rate, flow rate, and water temperature. Maintenance convenience: No mechanical component structure eliminates the risk of blockage, factory calibration features reduce maintenance frequency, and supporting software simplifies data management processes. This device provides a highly reliable and low-cost maintenance solution for monitoring drainage outlets and channels through dual optimization of technical parameters and structural design.
