1. Flow range of vortex flowmeter
The flow range of vortex flowmeter is mainly determined by the sensor diameter and fluid properties. The larger the diameter, the wider the measurable flow range. The conventional liquid measurement range is between 0.5m/s and 7m/s flow rate, and the gas measurement range is between 5m/s and 60m/s. 1. Correspondence between caliber and flow rate (under normal temperature water conditions) The flow range is directly related to the instrument caliber, and the following are typical parameters (referring to the product manuals of mainstream domestic manufacturers such as Chuanyi and Ganges in 2023): • DN15: minimum about 1.2 m ³/h, maximum about 15 m ³/h • DN25: minimum about 3 m ³/h, maximum about 40 m ³/h • DN50: minimum about 10 m ³/h, maximum about 150 m ³/h • DN100: minimum about 40 m ³/h, maximum about 650 m ³/h • DN200: minimum about 150 m ³/h, maximum about 2500 m ³/h • DN300: minimum about 300 m ³/h, maximum about 5500 m ³/h. 2. Influence of fluid medium • Liquid measurement (Water, oil, etc.): The flow rate range is usually 0.5-7 m/s, and liquids with viscosity higher than 30cP will significantly increase the measurement lower limit. Gas measurement (air search, steam, etc.): The flow rate range is usually 5-60 m/s, and low-pressure gases may have an increased lower limit flow rate due to low density. • Steam measurement: It is necessary to distinguish between saturated steam and superheated steam, and the flow range should be calculated based on temperature and pressure compensation to determine the actual mass flow rate. Avoid long-term use below the lower limit of 20%, otherwise the signal stability will deteriorate and errors will increase. • The maximum flow rate sh
4. The extended range ratio of the standard vortex flowmeter is 1:10~1:15, and models using dual sensors or digital signal processing technology can be extended to 1:20~1:30 (such as Emerson high-precision models), but the price is higher. The actual selection should be strictly based on the calculation of medium operating parameters (temperature, pressure, density, viscosity). It is recommended to directly use the selection software provided by the manufacturer or check the latest version of the product manual to obtain accurate data.
2. What are the functions of a vortex flowmeter?
Function
1. The body also integrates temperature and pressure compensation function, which can measure the standard volume flow rate or standard mass flow rate of the fluid..
2、 Fully intelligent and digital circuit design, capable of automatically compensating for measured fluid density or standard condition volume calculation.
3、 The new digital filtering and correction functions make flow measurement more accurate and reliable.
4、 The battery powered type can work continuously for more than two years without the need for an external power source.
5、 The brand new dot matrix Chinese character LCD display is more convenient to use and operate. Additional information: The flow range indicated in the instruction manual for common faults of vortex flow juice refers to the flow range used for specific reference media in the side nucleus, such as liquid, which generally refers to ambient water. When used for other media, the available flow range will vary depending on the viscosity,
