1. Is there a grade for flow meters?

Flow meters have a clear technical classification, with the most important being the accuracy grade. In some application scenarios, flow meters may also be labeled with pressure grade, explosion-proof grade, protection grade, etc.

1. Accuracy grade is the most important grade indicator for flow meters, which meets the requirements of relevant national standards for flow measurement in China. It is expressed as a percentage of the maximum allowable error to the measuring range. Common grades include 0.1 grade, 0.2 grade, 0.5 grade, 1.0 grade, 1.5 grade, 2.5 grade, etc. 1. Levels 0.1~0.5 belong to high-precision levels and are mostly used in scenarios that require high measurement accuracy, such as trade settlement, precise feeding of chemical raw materials, and filling of finished oil products. 2. Levels 1.0~2.5 belong to general precision levels and are mostly used in flow monitoring scenarios for municipal water supply networks, HVAC cycles, and ordinary industrial production lines.

2. Other technical grades (1) Pressure grade refers to the maximum working pressure that the flowmeter housing can withstand in the pipeline system, usually identified by PN (nominal pressure). Common specifications include PN

10, PN1

6, PN2

5, PN40, etc. When selecting, it must match the design pressure of the pipeline system to avoid overpressure causing shell rupture or leakage.

. （2） Explosion proof grade is used for working conditions where flammable and explosive media are present. According to the GB 3836 series explosion-proof national standards, common markings such as Ex d IIB T

4, Ex ia IIC T6, etc., where d represents explosion-proof type, ia

is intrinsic safety type, IIB/IIC is explosion-proof group, T4~T6 represents temperature group, and selection needs to be matched according to the current explosion-proof area grade. Such selection needs to be completed by qualified professionals. （3） The protection level is based on the GB/T 4208 standard for enclosure protection level, identified by IP (International Protection Shed Level). For example, IP65 represents complete dust prevention and can withstand low-pressure water spray, while IP67 represents complete dust prevention and can be submerged in 1 meter deep water for a short time. It is commonly used for flow meter selection in outdoor or humid conditions.

2. What is the measurement principle of multiphase flowmeter? Multiphase flowmeter (MPFM) is a core equipment used to simultaneously measure the flow rates of each phase in multiphase mixed fluids such as oil, gas, and water. It is widely used in fields such as petroleum extraction and chemical engineering. The core logic of its measurement is to first obtain the total flow rate/velocity of the mixed fluid and the volume fraction (phase fraction) of each phase, and then calculate the phase flow rate of each phase by combining it with the phase slip velocity model. Multiphase flow is much more difficult to measure than single-phase flow due to its complex flow pattern, uneven phase state, and slip velocity (different gas-liquid flow velocities). The mainstream technical routes are divided into three categories: separation type, premixed type, and online type without pretreatment. The following provides a detailed explanation of the principles, technical implementation, and core measurement methods.
1. Core Measurement Logic of Multiphase Flo
