What are the characteristics and installation forms of balanced flowmeter products?
The product features and installation form of HSP series balanced flowmeter are as follows:
1. Product features Key stimulated porous structure optimization flow field. Through porous design, the flow field is balanced and organized, significantly reducing vortex, vibration, and signal noise, and improving flow field stability.
. Its comprehensive performance meets the standards of high-end flow meters, with high precision, high stability, and high repeatability. The lower limit of flow is low, and it can accurately measure small flow rates. After optimizing the stability of the flow field, the demand for straight pipe sections has been significantly reduced, and the requirements for front and rear straight pipe sections have been lowered to front 3D and back 1D (where D is the diameter of the pipeline), reducing installation space requirements and saving pipeline costs. The permanent pressure loss is low, and the porous symmetric balance design reduces turbulent shear forces and vortex formation, lowers kinetic energy loss, thereby reducing pressure loss and improving system energy efficiency. Resistant to dirt and not easily clogged, reducing turbulent shear force and dead zone retention. Dirty media can smoothly pass through multiple holes, reducing the risk of blockage and extending maintenance cycles. The wide range ratio and flexible beta value range ratio are above 1:10, and the beta value can be selected within the range of 0.25-0.90, which is suitable for different flow measurement needs. The medium has excellent long-term stability and significantly reduces friction with throttling components. The β value re
2. Installation form for measuring gases (integrated installation, with the pressure tapping hole facing vertically upwards) is suitable for measuring gas media. The integrated design simplifies the installation process, with the pressure tapping hole facing vertically upwards to avoid condensation accumulation and ensure measurement accuracy.
. Measurement of steam (integrated installation, pressure tapping hole Yu Liangchang horizontally upward) is designed for steam media, with an integrated structure to reduce the risk of leakage. The pressure tapping hole is horizontally upward to prevent condensation water from flowing back and protect the pressure sensor. Measurement of steam (split type installation, pressure tapping hole level) The split type design is suitable for high-temperature steam or space limited scenarios, and the pressure tapping hole is horizontally arranged for easy discharge of condensate, ensuring long-term stable operation. It is recommended to install a horizontal pipeline for measuring liquids (integrated, vertical pipeline scraping, horizontal pressure pipe), and arrange the pressure pipe horizontally to avoid gas retention or sediment accumulation, ensuring the accura
